Simatic IOT2050 - industrial PC, IoT gateway - Siemens 6ES7647-0BA00-0YA2

Index: SIE-19859 EAN: 4034106033552
The Siemens Simatic IOT2050 smart, easily upgradable IoT gateway. The industrial gateway/computer acquires, processes, harmonizes and stores machine and production data from multiple sources directly on site at the production facility and then transmits it to a local server or the cloud, for example. The computer is based on an ARM TI AM6528 processor with an embedded graphics controller, 1 GB of DDR4 RAM and mPCIe slots and an Arduino compatible with Uno Rev3. The device is powered from 12 V to 24 V DC.
Simatic IOT2050 - industrial PC, IoT gateway - Siemens 6ES7647-0BA00-0YA2
€430.50
€350.00 tax excl.
Available
Shipping in 24 hours
PayPal payment
Manufacturer: Siemens

Product description: Simatic IOT2050 industrial computer, IoT gateway - Siemens 6ES7647-0BA00-0YA2

The Simatic IOT2050 smart, easily upgradable IoT gateway from Siemens. The industrial gateway/computer acquires, processes, harmonizes and records machine and production data from multiple sources directly on site at the production facility and then transmits it to a local server or the cloud, for example. The device easily connects to the open, cloud-based IoT operating system MindSphere developed by Siemens. The computer is based on an ARM TI AM6528 processor with an embedded graphics controller, 1 GB of DDR4 RAM and mPCIe slots and an Arduino compatible with Uno Rev3. The device is powered by 12 V to 24 V DC.

Komunikacja z Industial Edge oraz IIoT

Industrial Edge and IIoT communication.

Industrial Edge and IIoT communication

The Simatic IOT2050 computer will be easily integrated with Siemens' Industial Edge solutions. The gateway analyzes and processes machine and equipment data. The amount of data sent to the cloud is significantly reduced so that bandwidth can be used optimally. The Simatic IOT2050 intelligent IoT gateway connects internal IT, manufacturing and cloud departments and combines data from a wide range of data sources. The Simatic IOT2050 provides maximum performance with powerful Texas Instrument ARM processors and multiple interfaces such as mPCIe for wireless cards, Gbit LAN and two USB ports as well as one serial and one Arduinoport. The gateway is also configured not only for data transmission but also for data aggregation, conversion of a range of communication protocols and preprocessing in high-level languages such as Java, C++, Arduino IDE and Eclipse.

Simatic IOT2050 gateway specification
Model IOT2050
Type IoT gateway
Supply voltage 12 V to 24 V DC
Processor ARM TI AM6528 GP
Graphics controller embedded
Memory slot 1x microSD card slot
RAM 1 GB DDR4
Free slots 1x Arduino, 1x mPCIe
Number of digital inputs 20
Number of digital outputs 20
Output voltage from 3.3 V to 5 V DC
Interfaces

PFIBUS/MIPI via plug-in card

2x Ethernet

2x PROFINEX

2x USB 2.0

1x COM (RS 232 / 422 / 485)

Graphics interface 1x DisplayPort
Industrial Ethernet interface 2x RJ45 100 / 1000 Mb/s
Temperature sensor yes
Watchdog yes
Status LEDs yes
Degree of protection IP20
Storage temperature from -20°C to 70°C
Storage humidity 5% to 85% at 30°C non-condensing
Housing material Plastic, aluminum, stainless steel
Dimensions 37 x 142 x 100 mm
Package width 18 cm
Package height 16.5 cm
Package depth 3.8 cm
Package weight 0.52 kg
