Product description: Minicomputer UP 4000 2 GB RAM + 32 GB eMMC Intel Celeron N3350
The UP 4000 minicomputer is an efficient UP Board board based on the Intel Celeron N3350 processor, offering 2 GB RAM and 32 GB eMMC memory for smooth system operation. Equipped with USB A 3.2 gen. 1 ports, a USB C port and two USB 2.0 ports available via a 10-pin connector. Thanks to passive cooling and 12 V / 5 A power supply, it is suitable for industrial applications. The minicomputer is also equipped with an Ethernet and HDMI port, and includes accessories such as an RTC battery and a passive radiator. Perfect for embedded systems, automation and robotics.
The minicomputer works with Windows 10 - the license must be purchased separately.
UP 4000 minicomputer 2 GB RAM + 32 GB eMMC Intel Celeron N3350.
The UP 4000 series is the approximate size of a credit card.
Main features of the UP 4000 minicomputer
- Performance: The UP 4000 offers significant performance improvements over previous models, making it ideal for applications requiring fast and efficient data processing.
- Versatility: With a wide range of input/output interfaces, including industry standard 12V power, this mini computer is flexible and suitable for a variety of applications in industries such as automation and robotics.
- Extended memory options: UP 4000 is available in several versions with different memory sizes, which allows you to tailor the device to your individual needs.
- Diverse interfaces: has many output ports, including: video, audio line-in/out, and high-speed USB ports for easy integration with a variety of peripherals.
- Low energy consumption: the minicomputer has low power consumption, which allows you to save energy and reduce operating costs.
- Suitable for industrial applications: Thanks to its advanced features and robust design, the UP 4000 is the perfect solution for industrial applications, ensuring reliability and performance even in difficult operating conditions.
Arrangement of elements on the board
- 5.5/2.1mm DC jack for DC power
- FPC connector
- 6-pin connector (audio mic in/line out)
- 40-pin HAT connectors (GIPO, UART, I2C, SPI, PWM, I2S, ADC)
- 2x USB A 3.2 gen. 1
- 1x USB A 3.2 gen. 1
- 1x HDMI 1.4b supporting 4K 30Hz display
- 1x GbE
- 1x USB C 3.2 Gen 1 + DP 1.2 OTG supporting 4K 60 Hz display
- 4-pin connector (power and reset button)
- 10-pin connector (2x USB 2.0, HSUART)
- 2-pin power connector for the fan
- 2 GB RAM
- Intel Celeron N3350 processor
Arrangement of elements on the UP 4000 board.
The 40-pin GIPO connector provides freedom to expand the minicomputer .
Communication
- Ethernet: The UP 4000 is equipped with an Ethernet port, enabling a fast and reliable connection to the local network.
- USB: the minicomputer offers several USB ports, including USB A 3.2 gen. 1, USB C 3.2 gen. 1 and USB A 2.0, which allows you to connect a variety of peripheral devices.
- GPIO: Features a 40-pin GPIO connector that provides flexibility in integrating external devices and modules.
- Audio: The UP 4000 has a microphone input/audio line output, allowing you to connect audio devices.
- DisplayPort: the minicomputer is equipped with a DP 1.2 display port via USB Type C, allowing you to connect an external monitor or display.
- Wireless extensions: it is possible to expand the minicomputer with Wi-Fi, Bluetooth, and LTE / 4G / 5G modules via the M.2 connector, which enables wireless communication with other devices and provides access to the Internet.
Applications of the UP 4000 minicomputer
The UP 4000 minicomputer is widely used in various areas due to its efficiency, versatility and compact size . It is an ideal solution for applications related to process automation, device management and machine control in industry. Thanks to its advanced computing capabilities and communication interfaces, the UP 4000 minicomputer is used in the construction of robots and robot control systems . The UP 4000 can be used in checkout systems, payment terminals and for inventory management in retail stores, ensuring operational reliability and efficiency. This minicomputer can also be used to build advanced embedded systems, such as intelligent IoT devices or monitoring systems, and in Smart Home applications. Thanks to its flexibility and expandability, it will work well in various industrial, commercial and hobby applications, ensuring not only efficiency, but also reliability and versatility of operation.
UP 4000 minicomputer with Intel Celeron N3350 processor.
Technical specifications of the UP 4000 minicomputer
| Basic information | |
|---|---|
| Model | UP 4000 2GB / 32GB Intel Celeron |
| Technical Specifications | |
| Core | Intel Celeron N3350 64-bit |
| Operating Systems | Full version Microsoft Windows 10, Windows IoT Core, Linux (Ubuntu, Yocto) |
| Timing | 2.4GHz |
| RAM | 2GB LPDDR4 |
| Memory | 32 GB eMMC |
| GPIO socket | 40-pin connector |
| Power supply | 12 V / 5 A via DC 5.5 / 2.1 mm socket |
| Plate dimensions | 85.6 x 56.5 mm |
| Interfaces | |
| USB interface | 3x USB A 3.2 1 x USB C 3.2 2 x USB 2.0 on pins |
| Network interface | 1x GbE (Realtek RTL8111G-CG) |
| WiFi interface | Optional (via M.2 2230 on carrier board) |
| Bluetooth | Optional (via M.2 2230 on carrier board) |
| Camera | - |
| Touch display | 1x HDMI 1.4b 1x DP 1.2 via USB Type-C |
| Video | 1x HDMI 1.4b |
| Communication | UART, SPI, I2C, GPIO, PWM, ADC, I2S. |
| The remaining | 1x FPC connector to carrier board, RTC battery, passive heatsink, Power/Reset button |
