• EOL

Barometer BMP280 - Atmospheric pressure and temperature sensor - Unit expansion module for M5Stack development modules

Index: MSS-19117 EAN: 5904422363666
Unit type extension in form of barometer - atmospheric pressure sensor and temperature sensor. It has a built-in Bosch BMP280 chip. It enables air pressure measurement in the range from 300 hPa to 1100 hPa (including altitude estimation +9000 m ~ -500 m) with relative accuracy of +/- 0,12 hPa. The module also measures ambient temperature in the range of -40°C to +85°C. The measurement resolution is 0.01°C.
Barometer BMP280 - Atmospheric pressure and temperature sensor - Unit expansion module for...
€4.98
€4.05 tax excl.
Unavailable
Discontinued product
30-day returns
PayPal payment
Manufacturer: M5Stack
Compatibility: M5Stack Core M5Atom M5Stick

Attention!

The product has been discontinued. Check other products incategory.

Product description: Barometer BMP280 - atmospheric pressure and temperature sensor - Unit type extension module for M5Stack developer modules

Unit typeextension in a form of barometer -atmospheric pressureandtemperaturesensor. It has a built-in BoschBMP280chip. It allows to measure air pressure in the rangefrom 300 hPa to 1100 hPa(including altitude estimation +9000 m ~ -500 m) with relative accuracy of +/- 0,12 hPa. The module also measures ambient temperature in the range of-40°C to +85°C. The measurement resolution is 0.01°C.

Barometr BMP280 - czujnik ciśnienia atmosferycznego i temperatury - moduł rozszerzeń Unit do modułów deweloperskich M5Stack.

Barometer BMP280 - atmospheric pressure and temperature sensor - expansion

module Unit for M5Stack development modules.

Obsługiwany przez popularne środowiska programistyczne takie jak Arduino.
Supported by popular programming environments such as Arduino.

Technical specification of barometer

  • Type: atmospheric pressure sensor with built-in temperature sensor
  • Built-in circuit: BMP280
  • Pressure measurement range: from 300 hPa to 1100 hPa (+ 9000 m ~ -500 m)
  • Relative measurement accuracy: +/- 0.12 hPa
  • Absolute measurement accuracy: +/- 1 hPa
  • Temperature measurement range: -40°C to +85°C
  • Measurement resolution:
    • pressure: 0.16 hPa
    • temperature: 0.01°C
  • Sampling frequency: 2.7 μA at 1 Hz
  • Operating voltage: 1.71 V to 3.6 V
  • Communication interface: I2C bus
  • Interface address: 0x76
  • Module dimensions: 24 x 24 x 13 mm
  • Weight: 8 g

Features

  • Compatible withM5Stackseries of development modules
  • Supported programming platforms: Arduino, UIFlow (Blockly, Python)
  • Features an integrated 5-segment filter
  • Supports periodic measurements
  • Equipped with two LEGO compatible holes

Contents of the kit

  • Barometric Pressure Measurement Module - Expansion Unit
  • Connection cable with Grove connector - length 5 cm

In our shop you will also find otherUnittype extensions that will allow you to extend any project according to your individual needs.

W skład zestawu chodzi także dedykowany przewód połączeniowy o długości 5 cm.
The kit also includes a dedicated 5cm long connecting cable.
Sensor - type temp and pressure
Sensor - Temperature to 85 °C
Sensor - Temperature from -40 °C - 120 °C
